USB2.0 Camera Module
5MP USB Camera Module -OV5693
Supertek 5MP Auto Focus High-Definition USB2.0 Camera Module Color CMOS Sensor OV5693 with Digital Mic
- 5.0 Megapixel 2592H x 1944V
- USB 2.0 compliant, plug and play device
- OnmiVision OV5693 camera sensor
- PCB size: 50 * 20mm
- 4P 1.25mm SMT
- Fully customizable
Product Information
Supertek OV5693 Camera Module
Supertek 5MP USB2.0 camera module is based on Omnivision OV5693 CMOS sensor which is a high performance 1/4-inch, 5-megapixel image sensor, delivering super-quality imaging and low-light performance as well as full 1080p high-definition video recording at 30 frames per second (fps).It is a plug-and-play camera UVC compliant camera module for Windows and Linux, it is a driver free camera as well. This high resolution camera is the top-rated item with good price-performance ratio, which is suitable for the applications such as Kiosks, Access Control, Robots and face recognition. Our off-the shelf dimensions are 30*25mm, 62*10mm, 32*32mm, any other required dimension can be customized.
5MP USB Camera Module -OV5693- Specification
| Image Sensor | 1/4’’ OV5693 | |
| Pixel Size | 1.4um(H) x 1.4um(V) | |
| Resolution | 5.0 Megapixel 2592H x 1944V | |
| Output Format | MJPEG, YUV2 | |
| FOV | 66 degree | |
| Lens | EFL: 3.54mm F/NO: 2.0±5% | |
| Focus type | Auto Focus | |
| Shutter type | Electronic Rolling shutter | |
| Audio Input | Support | |
| Protocol & Connection | Plug & Play, UVC compliant | |
| Output & Power Supply | USB2.0 | |
| Power Socket | 4P 2.0mm SMT | |
| Supported OS | WinXP/Vista/Windows7(32bit/64bit)/Windows 8/Windows 10/MAC OSX EI captain 10.11.4 and Linux /Android | |
| Controllable Features | Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Backlight Contrast, Exposure | |
| Cable length | Default 1m USB cable | |
| Module Size | 50*20mm | |
| Operating Temperature | -20°C ~+70°C; | |
| Storage Temperature | -40°C ~+85°C; | |
| Humidity | 80 ~85% | |
| FORMAT | RESOLUTION | FRAME RATE |
| MJPEG | 2952×1944 | 30fps |
| 2560X1440 | 30fps | |
| 2048X1536 | 30fps | |
| 1920X1080 | 30fps | |
| 1280X720(720P) | 30fps | |
| 800X600 | 30fps | |
| 640X480(VGA) | 30fps | |
| YUY2 | 2952X1944 | 3fps |
| 2048X1536 | 3fps | |
| 1920X1080 (1080P) | 5fps | |
| 1280X720 (720P) | 10fps | |
| 640X480 (VGA) | 30fps | |
