USB2.0 Camera Module

5MP OV5647 Camera Module

Supertek 5mp USB camera module ST-OV5647FF comes with an OV5647 of 1/4’’ optical format, with a pixel size of 1.4um(H) x 1.4um(V).

  • 5.0 Megapixel 2592H x 1944V
  • USB 2.0 compliant, plug and play device
  • OnmiVision OV5647 camera sensor
  • PCB size: 30*25mm
  • 4P 1.25mm SMT
  • Fully customizable

Product Information

Supertek OV5647 Camera Module

The Supertek 5MP USB2.0 camera module is based on Omnivision OV5647 CMOS sensor which is a highest performance 1/4-inch, 5-megapixel image sensor, with the pixel size of 1.4 µm x 1.4 µm, results in the 5.0 Megapixel 2592H x 1944V image. This high-resolution camera is the top-rated item with a good price-performance ratio, which is suitable for the applications such as Document readers, Kiosks, Access controls, Robots, PC multimedia, and Electronics Device. It is a plug-and-play camera UVC-compliant camera module for Windows and Linux, it is a driver-free camera as well. Our off-the-shelf dimension is 30*25mm, any other required dimension can be customized.

5MP USB Camera Module -OV5647- Specification

Image Sensor1/4’’ OV5647
Pixel Size1.4um(H) x 1.4um(V)
Resolution5.0 Megapixel 2592H x 1944V
Output FormatMJPEG, YUV2
FOV65 degree
LensEFL: 3.54mm F/NO: 2.0mm
Focus typeAuto Focus
Shutter typeElectronic Rolling shutter
Audio InputSupport
Protocol & ConnectionPlug & Play, UVC compliant
Output & Power SupplyUSB2.0
Power Socket4P 2.0mm SMT
Supported OSWinXP/Vista/Windows7(32bit/64bit)/Windows 8/Windows 10/MAC OSX EI captain 10.11.4 and Linux /Android
Controllable FeaturesBrightness, Contrast, Saturation, Hue, Sharpness, Gamma, White balance, Backlight Contrast, Exposure
Cable lengthDefault 1m USB cable
Module Size30*25 mm
Operating Temperature-20°C ~ +70°C;
Storage Temperature-40°C ~ +85°C;
Humidity80 ~85%
FORMAT RESOLUTION FRAME RATE
MJPEG 2952×194430fps
2560X144030fps
2048X153630fps
1920X108030fps
1280X720(720P)30fps
800X60030fps
640X480(VGA)30fps
     YUY22952X19443fps
2048X15363fps
1920X1080 (1080P)5fps
1280X720 (720P)10fps
640X480 (VGA)30fps
