USB2.0 camera module

HD USB Endoscope Camera Module

Supertek 1MP HD USB2.0 endoscope camera is based on CMOS OV9734 image sensor. The sensor has a 1/9 inch optical format, which combined with the pixel size of 1.4 µm x 1.4 µm, results in 1280H x 720V images and videos. The on-chip ISP provides a very smooth AE (Auto Exposure) and accurate AWB(Auto White Balance) control. The USB endoscope is a Type-C port and is equipped with a Micro-USB interface and Type-A interfaces accessories.

  • HD 720P resolution with Fixed focus for your choice
  • 30fps at 1MP resolution
  • USB Connection, Easy Set-up, plug and play device
  • Moisture resistant and durable
  • Fully customizable
endoscope-in-medical

Product Information

Work in Multi Devices

USB2.0 micro and type-C interface

Work in Multi Devices

This endoscope allows you to detect under water, such as water tank, pipe and so on

4pcs 0201 LED

High brightness led chip

Application:
  • Automotive inspection
  • Pipeline inspection
  • Medical endoscope
  • Industrial PCB detection
  • Find out tiny spots that need fixing

HD USB Endoscope Camera - Specification

 ModelST10-9734FF
Image Sensor1/9 Inch CMOS OV9734
Pixel Size1.4um(H) x 1.4um(V)
Resolution1 Megapixel 1280H x 720V
Image ColorColor
FOV62 degree
LensF/NO: 3.0mm
Focus typeFixed Focus
Objective Distance20 to 55mm
WaterproofIP67
Output FormatMJPEG, YUV2
LED4pcs 0201 LED
Module Size19.25*3.65mm, Diameter 3.9 mm
Cable lengthDefault 2m USB cable
Output InterfaceUSB2.0 micro and type-C interface
