USB2.0 camera module

16MP Camera Module- IMX 298

Applications: Machine Vision, Inspection tester, Video Conference System.

  • 16MP resolution
  • Auto Focus/Fixed Focus
  • USB2.0 compliant, MJPEG streaming
  • Electronic Rolling Shutter
  • Fully customizable

Product Information

IMX 298 USB2.0 camera module

ST10-298AF is based on a Sony 1/2.8″ IMX298 CMOS image sensor, this 16MP HD USB2.0 camera has a dedicated, in-built Digital Signal Processor (DSP) that performs auto functions(Auto White Balance, Auto Exposure), the DSP has been tuned to achieve excellent image performance. The Frame Rate can be 30fps at 4K resolution.

It is a plug-and-play UVC camera module for Windows and Linux, it is a driver-free camera as well. This high-resolution camera is a top-rated item with a good price-performance ratio, which is suitable for the applications such as Machine Vision, drones, robotic vision, and video conference systems. Our off-the-shelf dimensions are 32*32mm, 28*28mm, and 62*13mm, any other required size can be customized.

16MP Camera Module-IMX 298 - Specification

Image Sensor1/2.8Inch CMOS IMX298
Pixel Size1.12umX1.12um
Resolution16 Megapixel 4656H x 3496V
Output FormatMJPEG
FOV78.4 degree
Image colorcolor
Focus typeAuto Focus
Shutter typeElectronic Rolling shutter
Audio InputSupport
Protocol & ConnectionPlug & Play, UVC compliant
Output & Power SupplyUSB2.0
Power Socket5pin 1.25mm socket
Supported OSWindows, Android, Linux, Wince, Mac OS
FORMATRESOLUTIONFRAME RATE
MJPEG4656×3496(16MP)8fps
4208×312010 fps
3264×2448(8MP)10 fps
2592×1944(5MP)10 fps
2048×1536(3MP)10 fps
1920×1080(1080P)15fps
1280X720(720P)30fps
640X480(VGA)15fps
